Type of hinge and corresponding use

Five parts manufacturers tell you the type of hinges and the use of gambling

General hinge

The hinge is fixed on the frame on one side and fixed on the fan on the other side. It can be turned open and is suitable for wooden doors and windows and general wood furniture.

Light hinge

The hinge plate is thinner and narrower than the general hinge, and is mainly suitable for light wooden doors and windows and general wood furniture.

Blind hinge

The hinge axis (pin) can be pulled out. After extraction, the door and window sash can be removed for easy scrubbing. It is mainly used on wooden doors and windows that need to be frequently disassembled.

Square hinge

The hinge plate is wider and thicker than the general hinge. It is primarily used on doors and windows or furniture with large components and scales.

H-shaped hinge

It is a type of core pull hinge, in which a piece of sheet can be loosened. It is primarily used on wooden doors or screen doors that need to be removed frequently.

T-shaped hinge

Suitable for wider door leaf, such as factory, warehouse gates, etc.

Scalloped hinge

The two sheets of the scalloped hinge are half thicker than the thickness of the general hinge, and are suitable for various windows and doors that require opening and closing.

Silent hinge

Also known as nylon washer hinges, when the door and window switches, the hinges are silent, and are mainly used on the doors and windows of public buildings.

Single flag hinge

The hinge is made of stainless steel, which is rust-resistant and wear-resistant, and is easy to disassemble. Mostly used on double-glazed windows.

Folding window hinge

When the device is installed, the two sheets with the mandrel should be installed on both sides of the window frame, and the two sheets without the mandrel should be installed on both sides of the window sash. A slotted, non-mandrel negative plate shall be placed on the side of the sash groove to allow the sash to be loaded and unloaded. Use for activities in factories, warehouses, residences, public buildings, etc.

Multi-function hinge

When the open angle is less than 75°, it has active sealing function, and it is self-stabilized when it is at an angular position of 75°-90°, and actively positioned when it is greater than 95°. This hinge can be used on the door instead of the general hinge.

Anti-theft hinge

Generally, when the shaft is pulled out, the door leaf can be removed, the anti-theft hinge, through the self-locking effect of the pin and the pin hole on the two pages of the hinge, the door leaf can be prevented from being unloaded, and the anti-theft effect is achieved. , applicable to the residence door.

Spring hinge

The door leaf can be actively closed after being opened, the single spring hinge can only be opened in one direction, and the double spring hinge can be opened in both directions. Primarily used on the gates of public buildings.

Double hinge

The two-axis hinges are divided into two types, which allow the door leaf to be freely opened, closed and disassembled. Suitable for general door and window sashes.

Screen door spring hinge

The door leaf can be actively closed after being opened, and can only be opened in one direction. The hinged pins can be pulled out to adjust and exchange the springs, which are mostly used on the solid steel structure screen doors.

Bearing hinge (copper)

Each of the hinges of the hinge has a one-way thrust ball bearing. The door switch is light and flexible, and is mostly used on heavy steel doors or special steel frame steel doors.

Beveled detachment hinge

This hinge utilizes the bevel of the hinge and the component of the door leaf to actively close the door. It is primarily suitable for use on light doors such as wooden doors or toilets.

Cold storage door hinge

Exterior baking finish, large steel plate, small cast iron. Used on cold storage doors or heavy insulation doors.
